Asia Pacific Industry Group Co., Limited

Home / Products/ POF cling film (Polyolefin Shrink Film - Tubular form

< >

POF Polyolefin Thermal (heat)Shrinkable Cling Film

Product code:

Wholesale price:

Description

Environmentally-friendly packaging film -POF Polyolefin Thermal (heat)Shrinkable Cling Film

Types:

1.) POF cling shink film -Center Folded (such as: 19mic x 45cm x 1000Mtr,30 mic x 585 mm x 1500 m)
2.) POF cling shink film - Tubular Form (such as: 25 mic x 330 mm x 1000 m)

3.) POF macro perforated cling film

Thickness :12-25 microns

Five layers of co-extruded polyolefin stretch POF thermal(heat) shrinkable film, breaking the traditional three-layers co-extruded film and the traditional of hot-stretching process, featuring a higher toughness and higher anti-impact strength in the line of packaging film industry, and it is the most advanced environmentally-friendly plastic packaging material.
Main features:
High-resolution, glossy transparent, protection, and to prevent products subject to affecting of dust, moisture and odor without the appearance of erosion.
Nice higher anti-crack-toughness and high anti-impact strength, keeping the relatively stable under high temperature and low temperatures, will not be broken, melted, broken ,decomposition and so on, suit for long-distance transportation and packaging of frozen products.
faster and higher Shrinking rate, applicable to the packaging of various shapes and sizes of products, strong toughness, light weight, thickness uniformity, and economy.
POF Thermal(heat)shrinkable film used for the beverage, food, medicine, packaging and other chemicals.
Main products: single-layer membrane, folded membrane, small roll specifications,

Test report of the POF cling film for reference :

Property 性能		Unit 单位	Test Method 测试方法		Representative Value 代表数值
Thickness 厚度		Micron			15		19	25
Density 密度		g/cm³			0.920		0.920	0.920
Yield 产量		㎡/kg			72.5		57.2	43.5
Tensile propeiries 拉伸性能
Elastic Modulus 坚韧度		N/mm²	ASTM-D882A		MD/TD		MD/TD	MD/TD
					340/350		340/340	360/450
Tensile Strength 拉伸强度		N/mm²	ASTM-D882		110/110		110/110	100/100
		%	ASTM-D882		110/110		110/110	105/105
Elongation@ break 拉伸极限
Seal Strength		g/cm³	Internal		870		1025	1250
封口强度		N/mm²			57		53	49
Tear Propagation 抗撕裂强度		g/cm³			5.5		9.5	14.5

COF.film to film.Kinetic 摩擦系数极限		adim.	ASTM-D1894		0.26		0.25	0.24
Free Shrink@125℃-140℃ 收缩率		%	ASTM-D2732		MD/TD 65/65		MD/TD 62/62	MD/TD 60/60

Optical Properties 光学性能		%	ASTM-D1003		1.3		1.8	3.0

Haze 雾度		photoc	ASTM-D2457		135		135	130
Gloss 光泽度




Specification of products
thickness		15 µ m		19 µ m		25 µ m
width		100mm-1500mm		100mm-1500mm		100mm-1500mm
length of roll	single	8750ft		7000ft		5250ft
	center fold	4370ft		3500ft		2185ft
		( English )
Thickness		15 µ m		19 µ m		25 µ m
Width		100mm-1500mm		100mm-1500mm		100mm-1500mm
Length	single wound	8750ft		7000ft		5250ft
per roll	center fold	4370ft		3500ft		2185ft			polyolefin

Ask questions now

Make an inquiry now

TECHNICAL PARAMETERS

1 Asia Pacific -Technical Specification For Shrinking Film 01-Compressed.pdf

2 Asia Pacific -Technical Specification For Shrinking Film 02-Compressed.pdf

3 Asia Pacific -Polyolefin Film TDS-Compressed.pdf

4 Asia Pacific -Polyolefin Film-FDA-Compressed.pdf

5 Asia Pacific -Polyolefin Film-SGS-Compressed.pdf

6 Asia Pacific -Polyolefin Film-ROHS--Compressed.pdf

7 Asia Pacific -MSDS-POF-Compressed.pdf

Ask questions now

Make an inquiry now

OFFER DETAILS

Environmentally-friendly packaging film -POF Polyolefin Thermal (heat)Shrinkable Cling Film

Types:

1.) POF cling shink film -Center Folded (such as: 19mic x 45cm x 1000Mtr,30 mic x 585 mm x 1500 m)
2.) POF cling shink film - Tubular Form (such as: 25 mic x 330 mm x 1000 m)

3.) POF macro perforated cling film

Thickness :12-25 microns

Test report of the POF cling film for reference :

Property 性能		Unit 单位	Test Method 测试方法		Representative Value 代表数值
Thickness 厚度		Micron			15		19	25
Density 密度		g/cm³			0.920		0.920	0.920
Yield 产量		㎡/kg			72.5		57.2	43.5
Tensile propeiries 拉伸性能
Elastic Modulus 坚韧度		N/mm²	ASTM-D882A		MD/TD		MD/TD	MD/TD
					340/350		340/340	360/450
Tensile Strength 拉伸强度		N/mm²	ASTM-D882		110/110		110/110	100/100
		%	ASTM-D882		110/110		110/110	105/105
Elongation@ break 拉伸极限
Seal Strength		g/cm³	Internal		870		1025	1250
封口强度		N/mm²			57		53	49
Tear Propagation 抗撕裂强度		g/cm³			5.5		9.5	14.5

COF.film to film.Kinetic 摩擦系数极限		adim.	ASTM-D1894		0.26		0.25	0.24
Free Shrink@125℃-140℃ 收缩率		%	ASTM-D2732		MD/TD 65/65		MD/TD 62/62	MD/TD 60/60

Optical Properties 光学性能		%	ASTM-D1003		1.3		1.8	3.0

Haze 雾度		photoc	ASTM-D2457		135		135	130
Gloss 光泽度




Specification of products
thickness		15 µ m		19 µ m		25 µ m
width		100mm-1500mm		100mm-1500mm		100mm-1500mm
length of roll	single	8750ft		7000ft		5250ft
	center fold	4370ft		3500ft		2185ft
		( English )
Thickness		15 µ m		19 µ m		25 µ m
Width		100mm-1500mm		100mm-1500mm		100mm-1500mm
Length	single wound	8750ft		7000ft		5250ft
per roll	center fold	4370ft		3500ft		2185ft			polyolefin
