BOPP/BOPET Capacitor Film clear

Polypropylene films BOPP Dielectric grade

1) Plain & Film for making suitable for High / Extra High Voltage Capacitors

2) Plain & Hazy Corona treated suitable for metalizing for making Metalized Film Capacitors)

1. BOPP capacitor film have two items, BOPP clear capacitor film and BOPP rough clear capacitor film.
1.)M-PP for metallized -film capacitors applications .
2.)S-PP for foil-film capacitors applications .
The standard thickness range including: 3 ,4,5,6,7,8,9,10,12 microns .
The standard tolerance thickness: +/-0.2 Um .
The width range including: can slit any width(MM )upon the requirement.
The inner core : 3" (76MM)
The outer core: 150-350 MM .
BOPP Capacitor film included RPP BOPP capacitor film,RRPP BOPP capacitor film, Polypropylene metallized capacitor Film (Zn metallized film,zn/al BOPP capacitor film),capacitor foil film
2. BOPP rough clear capacitor film .
1.)R-PP : one side of rough capacitor film ( power capacitor use).
2.)RR-PP: two sides of rough capacitor film .
The thickness range including: 6,7,8,9,10,12,18 microns .
The width range including: can slit any width (MM) upon the requirement.
The inner core : 3" (76MM),6'(152MM)
The outer core: 150-350 MM .
Features:1) single side corona treated for the Zn or Zn/Al metallized .

Specification
	①	MFZN（Alloy AlrZn)PP　8x23x2.5　R3.5　1S					3.5Ω
		PP t=８μ
					20.5mm
		2.5mm
				W=23mm
				20.5mm			2.5mm
				W=23mm
	②	MFZN（Alloy AlrZn)PP　6x30x2　R２　１S					2Ω
		PP t=6μ
					28mm
		2mm
				W=30mm
				28mm			2mm
				W=30mm
	③	MFZN（Alloy AlrZn)PP　９x50、52x4x2　R２　2S					2Ω
		PP t=9μ
			24mm			24mm
				W=52mm
		2mm					2mm
				W=50mm

2.  BOPET capacitor film (Polyester capacitor film) have two items: clear/transparent BOPET capacitor film and silver metallized BOPET capacitor film
1.) BOPET capacitor film were used for film-capacitor (and other electrical insulation material.) which features dielectric strength, dielectric constant and volume resistance, low dielectric loss, good mechanical performance and dimension stability.
BOPET capacitor film also called PET Capacitor film,clear Polyester capacitor film,transparent Polyester capacitor film,
Thickness:3-12UM  Width: 500,620,910,980,1010,1300 MM
Net weight per roll about: 50KGS/roll
Inner plastic tube core: 3',6'(76MM ,152MM )
2.) BOPET metalized VM/--Zn/Al capacitor film (Metallized BOPET Capacitor Film,sliver PET Capacitor film). Thickness:3-12UM    Width: 500,620,910,980,1010,1300 MM
