BOPP PEARLIZED FILM(BOPP WHITE OPAQUE FILM)

Product code:

Wholesale price:

Description

BOPP PEARLIZED FILM(BOPP WHITE OPAQUE FILM)

Is widely used for packaging application’s in surface printing . with both sides heat sealable. the film shows the pearlized white opacity appearance.

Thickness : 18,20,24,25,30,35,40,45 UM (microns)

Color : Silver whiteness with glossy pearl

Character: high heat strength ; excellent ultraviolet resistance ; excellent prarlized

Appearance ; high separative function

Applications: used for food ,chopsticksand ,gift ,soap package and freeze cold drink such as ice cream .thermal label ,sweet food ,biscuit ,snack food. As well can laminating with CPP or PE film .

Tech data for reference :
TYPICAL PROPERTIES	UNIT		TEST METHODS	TYPICAL VALUE
THICKNESS	micron		Micrometer	25
YIELD	m²/kg (min.)		-	59	49	42	35	28
DENSITY	g/cm³		ASTM D-1505	0.65-0.70	0.65-0.70	0.65-0.70	0.68-0.72	0.68-0.72
TENSILE STRENGTH	kg/mm²	MD	ASTM	6	6	6	6	6
TENSILE STRENGTH	(min.)	TD	D-882	12	12	12	12	12
ELONGATION AT BREAK	%	MD	ASTM	140	140	140	140	140
ELONGATION AT BREAK	(max.)	TD	D-882	50	50	50	50	50
THERMAL SHRINKAGE	%	MD	ASTM	4	4	4	4	4
(120° c 15 minutes)	(max.)	TD	D-1204	2	2	2	4	4
STATIC C.O.F.	film/film		ASTM D-1894	0.3 - 0.4	0.3 - 0.4	0.3 - 0.4	0.3 - 0.4	0.3 - 0.4
SEALING TEMPERATURE	°c		1 BAR 1 SEC	115	115	115	115	115
SEALING STRENGTH	g/cm (min.)		-	80	80	80	80	80
GLOSS (angle 45° )	% (min.)		ASTM	26	26	26	26	26
GLOSS (angle 45° )	% (min.)		D-2457	26	26	26	26	26
WVTR	g/m²/24 hr (max.)		ASTM F-1249	5	4.2	3.6	3.2	3
O₂TR	cc/m²/24 hr (max.)		ASTM D-3985	1,700	1,600	1,500	1,400	1,200
CORONA TREATMENT	Dyne/cm (min.)		ASTM D-2578	38	38	38	38	38

BOPP pearlized film(BOPP white opaque film）

Ask questions now

Make an inquiry now

TECHNICAL PARAMETERS

1 Asia Pacific- BOPP Pearl Film,Technology Data 25 38 40 Mic-Compressed.pdf

2 Asia Pacific- BOPP Pearl Technology Data2 -Compressed.pdf

3 Asia Pacific- BOPP Co-Ex Pearlized Opaque Film Technology Data3-Compressed.pdf

4 Asia Pacific- BOPP Pearl -38Micron Specification Buyer's Requirement-Compressed.pdf

5 Asia Pacific- BOPP Pearl - MSDS-Compressed.pdf

Ask questions now

Make an inquiry now

OFFER DETAILS

Specification of Milky White Film

Description : 40 & 50 Micron White Opaque Heat Seal Film
Width : 675 mm & 630 mm

S. No.	Properties	Units	Test Method	Specification
1	Film Thickness	Micron	Vendor	40 +/- 4%
2	GSM	Gm/Sq. Mtr	Vendor	38+/- 4%
3	Corona Traetment	Dyne/cm	ASTM D 2578	42~46
4	Haze/ Transmittance	%	ASTM D 1003	35 +/- 2
5	Gloss( Min.)	45 Degree	ASTM D2457	45
6	Coefficient of Friction Film/ Metal	-	ASTM D 1894	0.24
7	Static Half Line	Sec.	-	<5
8	Tensile Strength ( Min.)	Kg/cm Sq	ASTM D882	MD1200 TD 2400
9	Elongation ( max) at Break	%	ASTM D882	MD170 TD70
10	Modulas of elasticty ( Min)	Kg/cm. Sq	ASTM D882	MD18000 TD 28000
11	Linear Shrinkage( Max.)	%	5 Min at 120 deg. Cent. In Air	MD 4.0 TD 2.0
12	Useful Heat seal Range	Deg. Cent.	at 30 PSI 1 Sec Dwell Time	115~145
13	Heat Seal Strength	Gm/25 mm	120 Deg. Cent , 30 PSI 1 Sec. Dwell time	250

MD : Machine Direction
TD : Transfer Direction
