Heat sealable Polypropylene film

Item： Double sides Heat Sealable BOPP Specifications

Super clear and glossy BOPP film (Polypropylene film) with single/both side(s) corona treated. It is widely used in packaging industry such as printing, lamination and Aluminium metallization.
Featuring : Super high transparency and glossy,Super high tensile strength
Super high grease barrier, Excellent ink and coating adhesion
Low static electricity,Superior thickness uniformity
Smoothness of the vertical section and much compact of film rolls winding
BOPP film including BOPP plain film (BOPP flower film,BOPP tape-grade film,BOPP clothes/bag-grade film,BOPP mini/smaller roll,BOPP anti-static film);BOPP tobacco film; BOPP heat sealable film;BOPP matte film; BOPP pearlized film;BOPP thermal film; BOPP capacitor film;BOPP Sheets; BOPP anti-fog film; BOPP micro/ macro perforated film; Metallized BOPP film (VMBOPP); BOPP tear tape;BOPP laser film and so on.

Specifications

Thickness:12-75 micron  Width:350-1600 mm
Length:1000m,2000M,4000m ,6000m ,7000m, 8000m

Color: Transparent(clear).
Packing: use carton & pallets or as customers requirements
Customer's own requirement is available for us such as printed OEM logos and private label or particular size and package style.

Ask questions now

Make an inquiry now

1 Asia Pacific BOPP Two Sides Heat Sealable -Technical Data -Compressed.pdf

2 Asia Pacific BOPP Heat Sealable -Tds -Biaxially Oriented Polypropylene Film-Compressed.pdf

3 Asia Pacific BOPP Two Sides Heat Sealable-20micron-Compressed.pdf

4 Asia Pacific BOPP Two Sides Heat Sealable -25micron-Compressed.pdf

5 Asia Pacific BOPP Two Sides Heat Sealable -30micron-Compressed.pdf

6 Asia Pacific BOPP Two Sides Heat Sealable -35micron-Compressed.pdf

7 Asia Pacific BOPP Two Sides Heat Sealable -QC-Compressed.pdf

8 Asia Pacific BOPP Two Sides Heat Sealable-15-48microns-Compressed.pdf

9 Asia Pacific BOPP Two Sides Heat Sealable -18microns-Compressed.pdf

10 Asia Pacific BOPP Two Sides Heat Sealable -Bopp_Typical_Values_1-Compressed.pdf

11 Asia Pacific BOPP Two Sides Heat Sealable -Bopp_Typical_Values_2-Compressed.pdf

12 Asia Pacific BOPP Two Sides Heat Sealableb Opp-Compressed.pdf

Ask questions now

Make an inquiry now

Heat sealable Polypropylene film BOPP film

two-side coated, sealable OPP film used primarily as the outside web in laminations. Are sealable to other acrylic-coated and sealable PVdC-coated films. Arcylic coating and its properties are not affected by humidity.

FILM TECHNICAL SPECS:

Properties	unit	Test method	Tolerance	Typical value
Thickness	micron	--	±3%	20
Yield	m²/ kgm	--	±3%	55
Unit weight	gm/m²	--	±3%	18.2
Tensile strength MD TD	N/mm²	ASTM D 882	Min. Min.	120
				240
Breaking elongation MD TD	%	ASTM D 882	± 20 ± 10	160
				50
Modulus of elasticity MD TD	N/mm²	ASTM D 882	Min. Min.	2000
				3400
Heat shrinkage MD TD	%	In air, in oven for 5 min. at 130 ºC	Max. Max.	4
				2
Haze	%	ASTM D 1003	Max.	2.5
Gloss	G.U.	ASTM D 2457	Min.	85
Coefficient of friction	--	ASTM D 1894	± 0.05	0.3
Water vapor permeability	g/m².24 hrs at 38 ºC 90% RH	ASTM E 96-66 BS 3177	Max.	8.3
Oxygen permeability	Cc/m². 24 hrs Bar, at  23º C, 0% RH	ASTM D1434 Bs 2782 – 514 A	Max.	2200
Heat Seal Ring	ºC	OPMA METHOD	--	120 -145
Density	Kgm/m³	ASTM D 1505	± 0.05	0.91





FILM DESCRIPTION:

Two sides heat sealable; one side treated co extruded biaxial oriented polypropylene transparent film, suitable for:

• Rotogravure and flexographic printing.

• Lamination with similar films, paper or other films.

• Horizontal and vertical packaging machines (HFFS – VFFS).

• General over wrapping purposes.



CHARACTERISTICS

• Two sides heat sealable with excellent hot tack.

• High transparency.

• Excellent ink adhesion on treated side.

• High resistance to oil, grease, chemicals, puncture and abrasion.

• Good barrier to moisture, odors and gases.



APPLICATIONS:

Food packaging:

Biscuit, pasta, snacks, confectionary, chips, tea, and bakery.

Non–food packaging:

Stationary, textiles, gifts, and flowers.



ROLL SPECIFICATION:

Width N mm (or suitable to container size)

Inner diameter 76 mm （OR 3’’ ,6’’ ）

Outer diameter N mm (approx)
