BOPP高收缩香烟盒包装膜/ BOPP cigarette tobacco film generally used for soft/hard tobacco pack and used for modern high/slow packing machines.

transparent biaxially oriented polypropylene cigarette film featured coextruded heat sealable on both sides,incorporated with anti- static protection
Thickness : 18,19,20,21,22,25 Microns
Width: 90,110,118,120,135,150,220,350MM   Length:2000M,2800M,3000M,3500M
 Well-fitting to machine, suitable for high speed packing of all kinds of soft pack. Special hot slip ability on surface,can avoid machine-blocking,sticking etc. Quick heat sealing at low temperature and pressare. Good foldability after forming. Inferior optical properties to others.
Customer's own requirement is available for us such as printed OEM logos and private label or particular size and package style.
b.) Half-shrinkage BOPP Cigarette Film with heat sealable matches high-speed packaging machines.

Size: 22Microns*105mm*2800M

22Microns*110mm*2800M

22Microns*115mm*2800M

22Microns*118mm*2800M

22Microns*120mm*2800M

22Microns*125mm*2800M

22Microns*130mm*2800M

22Microns*135mm*2800M

22Microns*225mm*2800M

22Microns*350mm*2800M

22Microns*380mm*2800M

22Microns*420mm*2800M

c.) High-shrinkage BOPP Cigarette Film with heat sealable matches high-speed packaging machines.

3.) Specific property

Unit Typical numerical value  Testing Standard Grade AEC21 Grade AEC22 Corporate National International
 Density g/cm3 0.905 0.905 ASTM D1505
Thickness μm 21 22 Q/SD2 GB/T6672-2001
Unit weight g/m2 19.0 19.9
Yield m2/kg 52.6 50.3
Tensile strength MD N/mm2 160 150 Q/SD2 GB/T1040-1992 ASTM D882 TD 287 280
Elongation at break MD % 172 180 Q/SD2 GB/T1040-1992 ASTM D882 TD 63 60
Heat shrinkage MD % 3.5 3.2 Q/SD2 GB/T12026-2000 ASTM D1204-89 TD 2.8 2.5
Young’s modulus MD N/mm2 2200 1980 Q/SD2 ASTM D882 TD 3900 3300
Heat sealing strength N/15mm 2.6 2.7 Q/SD2 QB/T2358-1998 ASTM F88-94
Temperature range of heat sealing °C 120~150 120~150 Q/SD2 QB/T2358-1998 ASTM F88-94
Friction co-efficient 0.20 0.20 Q/SD2 GB/T10006-1988 ASTM D1894-93
Haze % 1.3 1.5 Q/SD2 GB2410-1980 ASTM D1003-95
(45°) Gloss % 85.0 85.0 Q/SD2 GB8807-1988 ASTM D2457

2. Usage

It is widely used in packaging soft and hard tobacco cigarette packets

3. acking: Use carton and kraft paper and bobble film to packing as inner package, and use pallets and wood board to packing as outer package

4. Featuring :

Super high transparency and glossy,Super high tensile strength
Super high grease barrier, Excellent ink and coating adhesion
Low static electricity,Superior thickness uniformity
Smoothness of the vertical section and much compact of film rolls winding

4. Technology data:
TYPICAL VALUES AND PHYSICAL PROPERTIES

Specification of Polypropylene film (PP Film)
Size: 100 mm. * 3,600 m.
Size: 115 mm. * 3,600 m.
Size: 122 mm. * 3,600 m.
1. Type Biaxially Oriented Polypropylene,
Maximum temperature seal does not over than 180 °C
2. Core Inside diameter of core 76mm., Thickness of core 8mm.
The length as width of PP Film
3. Thickness 0.018 – 0.024 mm.
4. Basis Weight 16 – 22 gms./ m²
5. Stiffness Not less than 11mm.
6. Heat – Seal Strength Not less than 300gms
7. Water Vapour Permeability Not over than 10gms/m²/24hours
8. Blocking Resistance Not tightly sealed at a pressure of 35 gms/m²
Period of 24 hours at 40°C, Humidity 40%
9. Odour Odourless
10. Haze Not over than 2.2%
11. Gloss : 45° Not less than 75%
12. General Appearance Tightly rol l
Incision is flat at both sides.
Seamless in the roll. If ne cessary the joints do not exceed
one mark per roll, But not over than 10% of each delivery.
By mark cleanly.
PS. the seller must specify the temperature when use

5. Standar Dimentions

OUR SERVICE

•Your inquiry related to our product & price will be replied within 24 hours.

•Well-trained & experiencd staff are ready to answer all your inquiries in English or other language.

•Working time: 8:30am – 17:30pm, Monday to Friday (UTC+8).

•Your business relationship with us will be confidential to any third party.

•Good after-sale service offered. Please feel free to contact us if you have any more information or question.

Q1: Are you A Manufacturer or A Trading Company?

A: we are not only More than ten years professional manufacturer and this is our factory's own import and export company. Mainly deal with oversea market’s exporting business!

But also have a specialty sales team of ages experienced international trade business. We can do transportation easily By sea, By air, By trains and by Air-express. Easily transact several transportation methods, such as mixed loading container, less than container loading, full container loading.

Here you’ll find up: Highly active, very convenient, professional specialty, vitality and vigor, zero-distance service!

Q2: Can you OEM and ODM?

A: We have high-advanced production equipment to ensure the quality of buyer’s order. Meanwhile there is a dedicated design team to help with the sample artwork for free. On the other hand your design will be 100% safe under NDA.

Q3: Can we get some samples from factory?

A: Yes, you can get available sample in our stock. Free for samples, but shipping fees is for buyer’s account. And after firm order, we will return the shipping fees to buyers or deduct the shipping fees from buyer’s firm order payment.

Q4: Can you accept the major currencies all over the world?

Yes, We can. And we can accept the payment currency, such as: USD, EUR,HKD,GBP,JPY,AUD,RMB(CNY) and so forth.

By the way, please highly noted: because many risks when buyer remite the payment to seller, for example, The network hacker: seller issue the PI ( Proforma invoice) to buyer, but when buyer send the advance deposit payment to seller, seller’s bank account was informed being changed, and let buyer send to the seller’s other nominated bank account. After seller send the payment to buyer, he won’t find the receptor forever. This is risk,.

So here we declare to all of our buyers:

Q5: How to control your quantity and quality?

A.   1) A complete quality guarantee system: IQC→ FAS & Self-checking for each process→ OQC;

    2) IS09001: 2008 system, SGS,  BV.COTECNA, SONCAP  approved

   3.) Third parties to inspection

Q6: How can we get a quote?

A: Buyer can get our quotation via Email (all of our email are @boppfilmsale.com), Tel, Fax, On-line Ali-trademanager, Mobile (cellphone) message, Skype,Msn, or any other methods. Please offer us the specification of the product that you need, then we will quote our price to you Within 2 hours during the working time, and within 12 hours during non-working time, and Within 24 hours during the holidays.
