BOPP 低温热封膜

产品编码:

批发价格:

分享 facebook

查看详情

立即咨询

产品描述

BOPP 低温热封膜/BOPP two sides lower heat seal temperature tobacco cigarette packs/boxes wrapping film clear transparent

Polypropylene in reels 132mm:

1- Description and using : polypropylene in bobbins which are used for wrapping cigarette soft packs on:

A) SASIB machines model CP1 which is amended to work on polypropylene instead of cellophane speed 150-200 pack/min

B) SASIB machines model CP1: speed 300 pack/min

C) GD Machines model C600

2- width: 132 mm+/-0.5mm

3- length: 3000m

4- internal bobbin diameter: 120mm+/-0.5mm

5- Grammage: 17-20g/m2

6- thickness: 19-22micron

7- glossing: 60% min

8- milting point: 160-166C

9- tension strength: 2 kg/15mm minimum

BOPP FIM POLYPROPYLENE SEALABLE BY BOTH SIDES.

DESCRIPTION

The film presents thermal sealability on both sides. This film contains an immigration package slip and antistatic additive that provides excellent machinability in all kinds of automatic packing.
The untreated side offers a wide range of sealing. The surface treatment is on the outside of the coil.

APLICATIONS

Designed to be used in a variety of conversion processes and packaging of all types of industrial and food products in casings or laminations.
Meets FDA regulations for direct food contact. Its properties allow it to be used sealants in numerous applications with sealed end flap or overlap in vertical or horizontal automatic packing.

Standar Dimentions

Thickness (um)	Weight (g/m2)	Wide (mm)	center carton	550mm External Diameter		760mm External Diameter
				length(m)	weight(Kg/cm)	length(m)	weight(Kg/cm)	Treated side
15	13.6			13.900		27.800
17.5	15.8			11.900		23.800
20	18.1	400		10.300		20.600
25	22.6	to	3” to 6”	8.250	1.89	16.500	3.77	External
30	27.2	2000		6.900		13.800
35	31.7			5.900		11.800
40	36.2			5.150		10.300
50	45.3			4.150		8.300

MAIN CHARACTERISTICS

Flexibility of use
Excellent antistatic properties
Magnific flatness and dimensional stability
One side treated for applying dyes or additives
outer surface treated to application of ink or additives
A wide sealing range


TYPICAL VALUES AND PHYSICAL PROPERTIES

PROPERTY			TEST METHOD	THICKNESS UM
PROPERTY		UNIT	TEST METHOD	12	15	25	30	35	40
OPACITY		%	ASTM D 1003	1.5		1.8		2.2
BRIGHT @ 45º		%	ASTM D 2457	80
COEFFICIENT OF FRICTION	TO/TO	¨¨¨¨¨¨	ASTM D 1894	0.20
COEFFICIENT OF FRICTION	T/T	¨¨¨¨¨¨	ASTM D 1894	0.35	0.25
TENSILE STRENGTH	MD	N/mm2	ASTM D 882	125
TENSILE STRENGTH	TD	N/mm2		235
ELONGATION AT BREAK	TD	%		180
ELONGATION AT BREAK	MD	%		50
DRYING MODULE @ 2%	MD	N/mm2		1.700
DRYING MODULE @ 2%	TD	N/mm2		3.000
CORONA TREATMENT		dinas/cm	ASTM 2578	38
SEALING TEMPERATURE	TN	ºc	ASTMF88/	105
SEALING TEMPERATURE	T	ºc		125
SEALING STRENGTH	TN	N/25mm		4.0				5.0
SEALING STRENGTH	T	N/25mm		3.5				5.5
WATER VAPOR TRANSMISSION		g/m2/dia	ASTM F 1249	8.5	6.5	5.6	4.7	4.3	3.8
@ 38ºC,90% HR		g/m2/dia	ASTM F 1249	8.5	6.5	5.6	4.7	4.3	3.8
OXYGEN TRANSMISSION		g/m2/dia	ASTM D 3985	2,900	2,200	1,800	1,600	1,400	1,200
@ 22ºC,0% HR		g/m2/dia	ASTM D 3985	2,900	2,200	1,800	1,600	1,400	1,200

NOTE :

MD MACHINE DIRECTION
DT TRANSVERSE DIRECTION
OT FACE NOT TREATMENT
T TREATMENT

the data in this data sheet should be used as guide values and not as specification limits

立即咨询

调查咨询

技术参数

1 Asia Pacific -BOPP Tobacco Film,Technology Data-Compressed.pdf

2 Asia Pacific -BOPP Tobacco Film,Technology Data2-Compressed.pdf

3 Asia Pacific -BOPP -TDS Data Sheet-Compressed.pdf

4 Asia Pacific -BOPP -Details Specifications Intruduce-Compressed.pdf

5 Asia Pacific -BOPP -QC-FDA-Compressed.pdf

6 Asia Pacific -BOPP -Poly Film Packet - Buyer Requirement-Compressed.pdf

7 Asia Pacific -BOPP -Heat Seal Tobacco Film EU-Compressed.pdf

8 Asia Pacific-BOPP -ROSH1-Compressed.pdf

9 Asia Pacific-BOPP -ROSH2-Compressed.pdf

10 Asia Pacific-BOPP -MSDS-Compressed.pdf
