supplier

Asia Pacific Industry Group Co., Limited

commodity

BOPET

Produce number

A270

Address

No.3399  Luzhou Ave.,Baohe Dist., 230051, Hefei, Anhui,China

size

PETT-6.0μm

Produce date

2018.8.01

tel

0551-64687285

item number

39206290

Inspect date

2018.8.06

Implementation of standards

GB/T16958-2008

quantity

Test sample volume

100%

Item

Standred

Test result

Result of each items

Appearance

Outliers

≤5/m²

satisfy

satisfy

Crack, relaxation, wrinkles, blemishes, impurities and defects affect the applicability of any

No obvious defects and affect the applicability

no

satisfy

End surface uniformity，mm

≤2.0

1

satisfy

Specifications

Width deviation，mm

±2

1

satisfy

Thickness deviation limit %

±6

-4.29

satisfy

The average thickness deviation%

±3

-1.14

satisfy

Physical mechanical properties

Tensile strengthMPa

Lateral

≥170

258.5

satisfy

Longitudinal

≥170

266.7

satisfy

Elongation at break%

Lateral

≤200

98.9

satisfy

Longitudinal

≤200

99.5

satisfy

Heat shrinkage,%

Lateral

≤3.0

2.36

satisfy

Longitudinal

≤3.0

0.06

satisfy

Modulus of elasticity,MPa

Lateral

/

4863

/

Longitudinal

/

4560

/

Coefficient of friction

Static friction

≤0.65

0.45

satisfy

Dynamic friction

≤0.55

0.46

satisfy

Wetting TensionmN/m

Treated surface

≥48

60

satisfy

Un-Treated surface

/

43

/

Gloss,%

≥100

128.9

satisfy

Haze,%

≤8.0

3.43

satisfy

Transmittance,%

/

90.5

/

Water vapor permeability（38℃，Relative humidity 0%，【g·0.1mm/(㎡·24h)】

≤6.6

3.2

satisfy

Oxygen permeability（23℃，Relative humidity 90%，【m³·cm/（c㎡·S·Pa）】

≤2.25×10^-15

1.85×10^-15

satisfy

Film roll joints

Shall comply with the requirements

satisfy

satisfy

Health Performance

GB9685-2008& GB13113 The provisions

Shall comply with the

satisfy

satisfy

There should be no odor smell

No odor

No odor

satisfy

Conclusions inspection

Gifted class

Remarks

Detecting people

Lin Min

Audit (stamped test chapter)

Fan Xiaowei
