BOPET聚脂薄膜1.2-500微米

产品编码:

批发价格:

分享 facebook

查看详情

立即咨询

产品描述

BOPET聚脂薄膜1.2-500微米/Transparent BOPET Film 1.2-500microns

Prouct Model: GTA/GT

Specifications:

Thickness

Width

Roll Dia.

Paper Core

1.2mic-5mic

50mm-2100mm

320mm-500mm

76mm (3 inches)

152mm (6 inches)

In sheets

Note: Other specifications can be produced according to customers’ requirements. Special requirements can be produced according to customers’ requirements.

Product Characteristic:

1. High transparency, good brightness.

2. Good surface smoothness, delicate and smooth.

3. Good physical processing and barrier properties, even heat distortion.

4. Good punching performance.

5. Small heat shrinkage.

Typical Properties:

Item	Unit	Typical Value		Test Method
Item	Unit	GTA	GT	Test Method
Thickness	UM	50	50	DIN 53370
Tensile Strength(MD/TD)	MPA	220/220	210/210	ASTM D 882
Elongation at Break(MD/TD)	%	140/130	170/150	ASTM D 882
Heat Shrinkage(MD/TD)150℃ 30min	%	1.5/1.5	1.5/0.5	ASTM D 1204
Elastic Modulus (MD/TD)	MPA	3800/3800	4000/4000	ASTM D 882
Haze	%	2.0	3.5	ASTM D 1003

Note: MD represents the vertical type, and TD represents the horizontal type.

The above data are gotten from the test data and it’s only for your reference.We suggest you’d better to test it by yourself before using. as the clients' use conditions is beyond our control.

Product Usage:

The products are applicable to the printing plate-making, label, tape, carton window film, gift cover light composite, hot transfer and paste, glitter powder sequin, document/photo protection, coating compound, etc.

立即咨询

调查咨询

技术参数

1 Asia pacific -6.0 Mic PET-Compressed.pdf

2 Asia Pacific -Technology Data Of 10 12 Mic PET Clear & Metallized-Compressed.pdf

3 Asia Pacific -Technology Data Of 12 23 36 ic BOPET -Compressed.pdf

4 Asia Pacific -Technology Data Of 100,150,250,350 Mic BOPET-Compressed.pdf

5 Asia Pacific -Technical Specification -BOPET 350Mic White 200,250 Mic Clear-Compressed.pdf

6 Asia Pacific -12Um BOPET Chemical Coating Film-Compressed.pdf

7 Asia Pacific -Vacuum Metallized Polyester Film-Compressed.pdf

8 Asia Pacific -150Um BOPET Clear And White-Compressed.pdf

9 Asia Pacific -Technology Data Of 50-250Mic BOPET-Compressed.pdf

10 Asia Pacific -Polyester Specification -4.5Mic BOPET COA -Compressed.pdf

11 Asia Pacific -10,12Microns Thermal Transfer BOPET Film No Corona Treatment-Compressed.pdf

12 Asia Pacific -Polyester Film Test Report-Compressed.pdf

13 Asia Pacific -Plain BOPET Film-Compressed.pdf

14 Asia Pacific -BOPET Heat Shrinkage Film-Compressed.pdf

15 Asia Pacific -MSDS 2 Of BOPET-Compressed.pdf

16 Asia Pacific -BOPET-FDA,Vcm,重金属,三聚氰胺等四项Heavy Metals, Melamine, Etc. (English)-Compressed.pdf

17 Asia Pacific -BOPET-EU,卤素,邻苯二甲酸盐或酯,甲醛,双酚A等五项Eu, Halogen, Phthalate Or Ester, Formaldehyde, Bisphenol A, Etc. (English)-Compressed.pdf

立即咨询

调查咨询

详细信息

Transparent BOPET Film 1.2-500microns

Prouct Model: GTA/GT

Specifications:

Thickness

Width

Roll Dia.

Paper Core

1.2mic-5mic

50mm-2100mm

320mm-500mm

76mm (3 inches)

152mm (6 inches)

In sheets

Note: Other specifications can be produced according to customers’ requirements. Special requirements can be produced according to customers’ requirements.

Product Characteristic:

1. High transparency, good brightness.

2. Good surface smoothness, delicate and smooth.

3. Good physical processing and barrier properties, even heat distortion.

4. Good punching performance.

5. Small heat shrinkage.

Typical Properties:

Item	Unit	Typical Value		Test Method
Item	Unit	GTA	GT	Test Method
Thickness	UM	50	50	DIN 53370
Tensile Strength(MD/TD)	MPA	220/220	210/210	ASTM D 882
Elongation at Break(MD/TD)	%	140/130	170/150	ASTM D 882
Heat Shrinkage(MD/TD)150℃ 30min	%	1.5/1.5	1.5/0.5	ASTM D 1204
Elastic Modulus (MD/TD)	MPA	3800/3800	4000/4000	ASTM D 882
Haze	%	2.0	3.5	ASTM D 1003

Note: MD represents the vertical type, and TD represents the horizontal type.

The above data are gotten from the test data and it’s only for your reference.We suggest you’d better to test it by yourself before using. as the clients' use conditions is beyond our control.

Product Usage:

The products are applicable to the printing plate-making, label, tape, carton window film, gift cover light composite, hot transfer and paste, glitter powder sequin, document/photo protection, coating compound, etc.
