BOPP/BOPET 电容膜镀锌铝膜/BOPP/BOPET Metallized Capacitor Film (silver)

Metallized BOPP/BOPET Capacitor Film (silver film) have two items :
1. Zn/Al Metallized BOPP/BOPET Capacitor Film (silver film)
2. Al Metallized BOPP/BOPET Capacitor Film (silver film)
Metallized BOPP/BOPET Capacitor Film were also called silver pp Capacitor film, zn/al BOPP capacitor film,Polypropylene metallized Film, Zn metallized capacitor bopp film, CBB capacitor metallized film
reinforced edge ( of Aluminum/Zinc film ) are : 1.5,2.0,2.5 MM

The standard thickness range including: 3,4,5,6,7,8,9,10,12 microns .
The standard tolerance thickness: +/-0.2 Um .
The standard width range including: 30,40,50,60,70,80,90,100,120,130 MM
The standard tolerance width: +/-5 MM.
The inner core : 3" (76MM)
The outer core: 150-350 MM .
Features:1) single side corona treated for the Zn or Zn/Al metallized .

立即咨询

调查咨询

1 Asia Pacific -BOPP Film For Capacitor Type MPP-Compressed.pdf

2 Asia Pacific -BOPP Capacitor-Usage Film Clear & Metallized-Compressed.pdf

3 Asia Pacific -BOPP Capacitor Clear & Metallized Film (Tech Data)-Compressed.pdf

4 Asia Pacific -Technical Data Of BOPP RPP & RRPP Rough Film-Compressed.pdf

5 Asia Pacific -BOPP-Introduction Of Metalized PP Film-Compressed.pdf

6 Asia Pacific -Tech Data -BOPP & BOPET-Compressed.pdf

立即咨询

调查咨询

BOPP/BOPET Metallized Capacitor Film (silver)

Metallized BOPP/BOPET Capacitor Film (silver film) have two items :
1. Zn/Al Metallized BOPP/BOPET Capacitor Film (silver film)
2. Al Metallized BOPP/BOPET Capacitor Film (silver film)
Metallized BOPP/BOPET Capacitor Film were also called silver pp Capacitor film, zn/al BOPP capacitor film,Polypropylene metallized Film, Zn metallized capacitor bopp film, CBB capacitor metallized film
reinforced edge ( of Aluminum/Zinc film ) are : 1.5,2.0,2.5 MM

The standard thickness range including: 3,4,5,6,7,8,9,10,12 microns .
The standard tolerance thickness: +/-0.2 Um .
The standard width range including: 30,40,50,60,70,80,90,100,120,130 MM
The standard tolerance width: +/-5 MM.
The inner core : 3" (76MM)
The outer core: 150-350 MM .
Features:1) single side corona treated for the Zn or Zn/Al metallized .
