超薄BOPET银色镀铝膜

超薄BOPET银色镀铝膜

产品编码:

批发价格:

分享 facebook

超薄BOPET银色镀铝膜/4.5，6.0 Microns BOPET Film silver metallized

4.5,6.0 Microns BOPET Film silver metallized, Bopet polyester metallized film has a super reflective, mirror- like surface. It is a oriented polyester film with a very

thin coating of aluminum that is vacuum deposited on to the surface of the film. This film is used in a variety of

industrial and applications, including printing, packaging, crafts and many other applications.

Main features of bopet polyester metallized film

a. Good Metal Bond Strength

b. Good Barrier properties of oxygen, light, water vapor

c. Good Lamination Bond Strength

d. Excellent Machinability

Technical Performance:

No.	Properties		Unit	Value		Test Method
1	Standard Thickness		4.5 microns
2	Film Thickness Tolerance		%	≤	5	ASTM-D374
3	Tensile Strength	MD	MPa	≥	200	ASTM-D882
	Tensile Strength	TD		≥	200
4	Elongation at Break	MD	%	≥	100
	Elongation at Break	TD		≥	100
5	Heat Shrinkage(150°C/30min)	MD	%	≤	1.5	ASTM-D1204
	Heat Shrinkage(150°C/30min)	TD		≤	0.5
6	Wetting Tension		mN/m	≥	52	ASTM-2578
7	WVTR		g/m2.24h	≤	3.5	ASTM-F1249
8	OTR		cm3/(m2.24h.0.1MPa)	≤	15	ASTM-F1927
9	Strong adhesive strength		%	≤	20	---
10	Aluminum-plate thickness		OD	≥	2.0	---
11	Aluminum-plate equality		%	±	15

技术参数

超薄BOPET银色镀铝膜/4.5，6.0 Microns BOPET Film silver metallized

立即咨询

调查咨询

超薄BOPET银色镀铝膜/4.5，6.0 Microns BOPET Film silver metallized

4.5 Microns BOPET Film silver metallized, Bopet polyester metallized film has a super reflective, mirror- like surface. It is a oriented polyester film with a very

thin coating of aluminum that is vacuum deposited on to the surface of the film. This film is used in a variety of

industrial and applications, including printing, packaging, crafts and many other applications.

Main features of bopet polyester metallized film

a. Good Metal Bond Strength

b. Good Barrier properties of oxygen, light, water vapor

c. Good Lamination Bond Strength

d. Excellent Machinability

Technical Performance:

No.	Properties		Unit	Value		Test Method
1	Standard Thickness		4.5 microns
2	Film Thickness Tolerance		%	≤	5	ASTM-D374
3	Tensile Strength	MD	MPa	≥	200	ASTM-D882
	Tensile Strength	TD		≥	200
4	Elongation at Break	MD	%	≥	100
	Elongation at Break	TD		≥	100
5	Heat Shrinkage(150°C/30min)	MD	%	≤	1.5	ASTM-D1204
	Heat Shrinkage(150°C/30min)	TD		≤	0.5
6	Wetting Tension		mN/m	≥	52	ASTM-2578
7	WVTR		g/m2.24h	≤	3.5	ASTM-F1249
8	OTR		cm3/(m2.24h.0.1MPa)	≤	15	ASTM-F1927
9	Strong adhesive strength		%	≤	20	---
10	Aluminum-plate thickness		OD	≥	2.0	---
11	Aluminum-plate equality		%	±	15	---

立即询价

立即咨询

调查咨询

Technical Performance:

No.	Properties		Unit	Value		Test Method
1	Standard Thickness		4.5 microns
2	Film Thickness Tolerance		%	≤	5	ASTM-D374
3	Tensile Strength	MD	MPa	≥	200	ASTM-D882
	Tensile Strength	TD		≥	200
4	Elongation at Break	MD	%	≥	100
	Elongation at Break	TD		≥	100
5	Heat Shrinkage(150°C/30min)	MD	%	≤	1.5	ASTM-D1204
	Heat Shrinkage(150°C/30min)	TD		≤	0.5
6	Wetting Tension		mN/m	≥	52	ASTM-2578
7	WVTR		g/m2.24h	≤	3.5	ASTM-F1249
8	OTR		cm3/(m2.24h.0.1MPa)	≤	15	ASTM-F1927
9	Strong adhesive strength		%	≤	20	---
10	Aluminum-plate thickness		OD	≥	2.0	---
11	Aluminum-plate equality		%	±	15	---
