BOPET聚酯薄膜光膜 4.5微米

4.5微米 热转印碳带色带（TTR）用BOPET聚酯薄膜

BOPET 薄膜 4.2微米

4.5MIC BOPET TTR碳带膜

BOPET TTR 热转印聚酯薄膜 4.4/4.5微米

BOPET TTR 聚酯薄膜 4.4/4.5微米

本产品属于超薄膜， 也属于BOPET生产过程中，技术含量仅次与BOPET电容膜的产品类别，属于BOPET TTR即热转移，热转印专用膜。

产品主要规格和品种如下：

1.） 分为表面有单面涂层，和表面无涂层， 目前都是无涂层的光膜为主。

2.） 厚度：3.8,4.0,4.2,4.4,4.5,4.55,4.6,4.8,5.3,5.7,6.0微米（其中主要的标准的厚度是4.4和4.5微米）

3.） 宽度：620,640,650,730,780,750,900,910,930,990,1010,1040,1090,1110,1250,1370,1400,1460,1570,1650MM...（其中主要的宽度是 910,1010）

4.） 长度是：12000,15000,16300,18500,24000,36000,44000,55000,65000M。（其中主要的长度是 16300 和18500米）

5.）纸管：6英寸（152毫米）

6.） 包装：托盘+栈板包装， 横式悬空 包装和纸箱托盘包装。（特殊情况有可以单卷简包）

7.） 装柜数据：12吨/1*20‘GP ，23.5吨/1*40‘

因这个品种在生产过程中，有浪费，所以市场价格较高，次品率存在（薄膜褶皱，表面净化不干净，有黑点，带接头，或者是薄膜厚薄不均匀）。

BOPET 薄膜 4.2微米

4.5MIC BOPET TTR碳带膜

BOPET TTR 热转印聚酯薄膜 4.4/4.5微米

BOPET TTR 聚酯薄膜 4.4/4.5微米

BOPET聚酯薄膜光膜 4.5微米

4.5微米 热转印碳带色带（TTR）用BOPET聚酯薄膜

立即咨询

调查咨询

1 Asia Pacific -4.5Mic BOPET Film Packing And Factory Product Lines Show -Compressed.pdf

2 Asia Pacific -4.5Microns BOPET Film Technology Date Sheets -Compressed.pdf

3 Asia Pacific -Analysis Of 4.5Mic BOPET Sample From The USA Buyer Of Asia Pacific Industry Group.pdf

立即咨询

调查咨询

BOPET polyester film 4.2microns

BOPET Film for Thermal Transfer Ribbons type TTR

1、 Characteristics

It is stretched in biaxial orientation by mean of flat film method by using

imported polyethylene terephthalate in electrical grade. With good mechanical

properties, and thermal characteristics, it has excellent engineering properties

in coating process.

2、 Applications

As a kind of substrate, it is widely applied to a variety of bar code printing,

advertising banner printing, label printing, photo printing and other industries.

3、 Specifications

Size(μm) WMV(μm) MMV(μm) Test method

4.0 4.0±0.1 4.2±4%

GB/T

13542.2-2009/4

4.3 4.3±0.1 4.5±4%

4.5 4.5±0.1 47±4%

Width of the finished film

roll

mm

700±2, 910±2,1010±2 oras customer’s requirement

700±2,910±2,1010±2

Inner diameter （D0） mm Φ152.4

picture Outer diameter （D） mm 350-550

Note:For special specifications, please discuss with us separately.

4、Thickness Representation

The nominal value of the film thickness is indicated by the central value

(integer value, such as 3,5,7,10,15) of film thickness plus mantissa (one point after

decimal point) or its code. Our nominal value for BOPET film thickness is represented

in WMV.
